Collecting Pans for Muffle and Ashing Furnaces
Product number:
6206988
Manufacturer:
Nabertherm GmbH
Packaging information:
Length:
237 mm
Width:
187 mm
Height:
80 mm
Weight:
0.617 kg
Description
Ceramic collecting pans for temperatures up to max. 1300 °C, steel collecting pans for temperatures up to max. 1100 °C.
Properties
| Depth: | 170 mm |
|---|---|
| Dimensions (WxDxH): | 190 x 170 x 20 mm |
| For: | LE 6/L 5/LT 5/LV 5/LVT 5 |
| Height: | 20 mm |
| Manufacturer Article Number: | 691600511 |
| Material: | Ceramic |
| Max. temperature: | 1300 °C |
| UNSPSC: | 41-10-24-26 |
| Width: | 190 mm |
