Vacuum pump systems LABOPORT® SR 820 G / SR 840 G
Product number:
4684032
Manufacturer:
KNF NEUBERGER GmbH
Packaging information:
Weight:
16.15 kg
Description
Vacuum pump system, consisting of chemically resistant diaphragm vacuum pump, base plate and two separator flasks on suction and pressure side, for filtrations, degassings fluid aspirations centrifugal concentrations and vacuum ovens. The PTFE pump head and the PTFE-coated diaphragm make the vacuum systems suitable for aggressive / corrosive gases and vapours.
- 100 % oil-free transfer
- High level of vapor and condensate compatibility
- Integrated gas ballast valve
- 3-colour status display (in operation / stand-by / error)
- Integrated speed control
- Start against ultimate vacuum of the pump
- Modular expandable
Properties
| Connection pressure side: | ID 10 mm |
|---|---|
| Connection suction side: | ID 8 ... 9,5 mm |
| Depth: | 274 mm |
| Dimensions (WxDxH): | 299 x 274 x 250 mm |
| Flow rate: | 34 l/min |
| Height: | 250 mm |
| IP code: | IP 30 |
| Manufacturer Article Number: | 325240/315994 |
| Max. permitted ambient temperature: | 40 °C |
| Max. voltage: | 240 V |
| Min. permitted ambient temperature: | 5 °C |
| Min. voltage: | 100 V |
| Plug type: | EU/UK/CH |
| Power supply: | 100 ... 240 V |
| Rated capacity: | 100 W |
| Type: | SR 840 G |
| Type of auxiliary energy: | Mains connection |
| UNSPSC: | 40151502 |
| Ultimate vacuum: | 6 mbar |
| Weight: | 13.1 kg |
| Width: | 299 mm |
