Rotary vane pump RZ 2.5, two-stage, package
Product number:
4691568
Manufacturer:
Vacuubrand GmbH & Co.KG
Packaging information:
Weight:
20 kg
Description
The powerful rotary vane pumps are ideal for laboratory and process applications that require a very good ultimate vacuum at medium gas flow rate. Typical applications are lyophilisation, fine vacuum distillation, and evacuation of small volumes.
Scope of supply: Rotary vane pump, oil mist filter FO, butterfly valve VS 16, manual
- Compact design and low weight
- High flow rate even at vacuum levels approaching ultimate vacuum
- Very good ultimate vacuum even with gas ballast
- Vacuum-tight at switch-off without suction nozzle valve
- Long oil change intervals due to large usable oil volume
- Easy maintenance due to telescopic design
Properties
| Connection pressure side: | DN 8-10 mm |
|---|---|
| Connection suction side: | KF DN 16 |
| Depth: | 390 mm |
| Dimensions (WxDxH): | 230 x 390 x 240 mm |
| Flow rate: | 38.33 l/min |
| Height: | 240 mm |
| IP code: | IP 40 |
| Manufacturer Article Number: | 20798029 |
| Max. voltage: | 230 V |
| No. of stages: | 2 |
| Noise level: | 48 db(A) |
| Plug type: | CEE |
| Power supply: | 230 V, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Rated capacity: | 100 W |
| Type: | RZ 2.5+FO+VS 16 |
| Type of auxiliary energy: | Mains connection |
| UNSPSC: | 41105109 |
| Ultimate vacuum: | 0.002 mbar |
| Ultimate vacuum with gas ballast: | 0.01 mbar |
| Weight: | 15 kg |
| Width: | 230 mm |
