CHROMABOND® vacuum manifolds and accessories
Product number:
6274944
Manufacturer:
Macherey-Nagel GmbH & Co. KG
Packaging information:
Length:
461 mm
Width:
230 mm
Height:
272 mm
Weight:
3.985 kg
Description
For simultaneous preparation of up to 12 or 24 samples, replacement parts and accessories for special applications.
Vacuum manifold complete consists of: glass cabinet with lid and lid gasket, removable needles on lower side of lid, vacuum gauge, control valve, valves and caps, variable rack.
Vacuum manifold complete consists of: glass cabinet with lid and lid gasket, removable needles on lower side of lid, vacuum gauge, control valve, valves and caps, variable rack.
Properties
| Description: | Vacuum manifold for 12 columns or cartridges |
|---|---|
| Manufacturer Article Number: | 730150N |
Skip product gallery
CHROMABOND® HR-X
From
€72.50*
CHROMABOND® SiOH
From
€108.00*
CHROMABOND® SB
From
€142.00*
CHROMABOND® Florisil®
From
€108.00*
CHROMABOND® PS-OH- / PS-H+
From
€124.00*
CHROMABOND® Alox A / Alox N / Alox B
From
€117.00*
CHROMABOND® PA
From
€142.00*
CHROMABOND® XTR
From
€72.50*
Similar products
Spherical, hydrophobic polystyrene-divinylbenzene resin for SPEHydrophobic polystyrene-divinylbenzene copolymer pH stability 1 to14. High-purity material with highest reproducibility and lowest blank values due to a novel manufacturing process, spherical particles 85mm; pore size 55 to 60Å. Very high surface 1000m²/g; capacity 390mg/g (caffeine in water). Excellent recovery rates especially for the enrichment of pharmaceuticals/active ingredients due to the spherical structure of the particles, very homogeneous surface, and optimised pore structure.Recommended applications: pharmaceuticals/active ingredients from tablets, creams and water/waste water, drugs and pharmaceuticals from urine, blood, serum and plasma trace analysis of pesticides.Cartridges in further sizes and phases of the HR-X poduct range available on request.
Unmodified silica phase for SPEUnmodified, weakly acidic silica, pore size 60Å, particle size 45µm, specific surface 500m²/g, pH stability 2 to 8, very polar, adsorbs humidity from air, for this reason it should be kept well closed and if necessary dried before use due to its high affinity for polar compounds it should not be conditioned with polar (e.g. methanol) or water-containing solvents.Recommended applications: aflatoxins, chloramphenicol, pesticides, steroids, vitamins.
Quaternary ammonium modified silica anion exchanger for SPE (SAX)Base material silica, pore size 60 Å, particle size 45 µm, specific surface 500 m²/g, pH stability 2 to 8. Silica modified with quaternary amine. Strongly basic anion exchanger (capacity ~ 0.3 meq/g). Not suited for very strong anions such as sulphonic acids, because these are difficult to elute.Recommended application: organic acids, caffeine, saccharin.
Magnesium silicate for SPEMatrix magnesium silicate (MgO to SiOH 15:85), high purity, particle size 150 to 250µm.Recommended application: organic tin compounds, aliphatic carboxylic acids, PCB, PAH.
The innovative cation exchanger offers:mixed-mode SPE phase with distinct cation exchange and RP properties excellent enrichment of basic analytesmodern support polymer with optimised pore structure and large specific surfacegood reproducibility, reliable and cost-efficient analysesmore aggressive washing procedures for matrix removal possiblecleaner samples and protection of analytical HPLC and GC instrumentationquantificationof analytes from heavily contaminated sampleslower limits of detection also for critical matrices... the perfect fit for basic analytes in comination with CHROMABOND® HR-XSPE phases for polymer-based RP and ion chromatographyBase material: high-purity polystyrene-divinylbenzene copolymers (PS/DVB) pore size 100 Å, paricle size 100µm. Verly low degree of swelling, thus very well suited for chromatography. Different modifications for different applications from elimination of nonpolar compounds up to removal of specific polar comonents.Recommended application:Removal of interfering compounds improves chromatographic separtions, if the interfering components overlap with the analyte in the chromatogramimproves lifetime of the chromatographic column, since interfering components can irreversibly block the column packing
aluminium oxide, acidic, neutral, basicaluminium oxide, high purity, pore volume 0.90ml/g, particle size 60 to 150µm, specific surface 150m²/g, acidic, pH 4 ± 0.5, recommended application: together with phase SA for PCB and pesticides.Alox A: acidic, pH 4 ± 0.5Alox N: neutral, pH 7 ± 0.5Alox B: basic, pH 9.5 ± 0.5
Polyamide 6 for SPEMatrix polyamide 6, unmodified, high purity, particle size 40 to 80µm.Recommended application: flavonoids, PAH.
Kieselguhr phase for liquid-liquid extractionBase material coarse-grained kieselguhr, large pore size, high pore volume, constantly high batch-to-batch quality, pH working range 1 to 13.Application: liquid-liquid extraction of highly viscous aqueous solutions such as physiological fluids (blood, plasma, and serum) in clinical chemistry, dyes in textiles, environmental and food analysis.Glass columns availlable on request.
