Accessories for EBI 25 data loggers

Description:	Software Winlog.web
Manufacturer Article Number:	1340-2490

Standard PDF data logger EBI 300 TH

PDF data logger with external humidity and temperature sensor TPH 400, internal temperature sensor can also be used.For temperature monitoring related to HACCP/IFS issues or other perishable goodsTransportation of fresh, cool and deep cool productsMonitoring of fridges and deep freezersEvaluation without software, PDF are automatically generatedMinimise training, user errors and IT costs using EBI 300's simple, easy to use design and standard softwareEnsure data integrity since no data manipulation is possibleEN 12830, ATP, VO(EG) 37/2005 CompliantFactory calibration certificate includedProgrammable via the free online configurator at www.ebi300.comNo separate interface for programming and readingMemory: 40000 samplesMeasuring modes: Start/Stop, endless loop, start with buttonAlarms: 2 values, high and low limits

From €167.00*

Temperature-humidity logger LOG32TH

Data logger for monitoring and recording temperature and humidity during the storage and transportation of sensitive products. Measurement data can be transferred to a PC via the integrated USB interface, and evaluated and documented using the free LOG CONNECT software.Incl. calibration certificateMemory for 2 x 60000 data recordsUsable without software, with pre-programmed reading interval of 5 minutesFreely adjustable recording interval from 30 seconds to 24 hoursAutomatic output as PDF file (logger is recognized like USB memory stick)Battery life >2 years (with recording interval >5 minutes)Status and alarm LEDsIncl. wall mount and battery (1/2 AA, 3.6 V)Application profile:Quality monitoring in the laboratory, during production or in the warehouseAmbient conditions in production facilitiesMonitoring storage and transport conditions in accordance with HACCPAmbient conditions in power plantsMonitoring of refrigerators for pharmaceuticals

From €79.00*

Temperature / Humidity data logger LOG 210

PDF-data logger with displayMemory size: 100.000 measurementsUsable without software (default settings) (5-minute-interval, without alarm settings)Automatic PDF creationMovement sensor for shock recording e.g.: door or windows closingFree adjustable recording interval: 10 seconds to 24 hoursMax-Min-Display memory (resettable)Time marking functions for measuring resultsBattery lifetime approx. 4 years (recording interval >15 minutes)Status- and Alarm-LEDsIncludes wall mountFree software LogConnect, for configuring (alarms, interval, changing display settings) or LogGraph2 for comfortable graphical and tabular display of measured values, incl. drag and zoom. Software is available as download.SpecificationsTemperatureMeasuring range:-40 to +70 °CAccuracy:0.1 °CPrecision:±0.5 °C (0 to +60 °C), otherwise ±1.0 °CHumidityMeasuring range:0 to 100 % R.H.Resolution:0.1% R.H.Accuracy:±3 % R.H. (40 to 60 %), ±3.5 % R.H. (20 to 40 % and 60 to 80 %), otherwise ±5 % R.H.Interface: Housing:USB (integr.) Plastic (ABS)Battery:1 x 3,6 Volt Lithium ½ AADimensions:91.5 x 42 x 20 mmWeight:approx. 70 g

From €79.00*

Temperature/Humidity data logger EBI 20-TH1

Applications:Reliable temperature and temperature/humidity recordingTransportStorage monitoringRefrigeration areas and coldroomsFeatures:Excellent price/performance ratioVisual AlarmMax./min. values on displayStores 40000 readings, can be read off at any timeReplaceable batteryMeasuring mode: immediate loop measurement, measurement from starting point, start immediately until memory full, start/stop measuring, start when button pressedScope of supply: Temperature/Humidity logger

From €70.56*

Stainless steel sintered filter AH 300

The stainless steel sintered filter increases the protection class to IP 40. The stainless steel used increases the mechanical protection and is highly resistant to corrosion, even in high-temperature applications.

From €98.00*

WiFi Temperature-humidity logger testo Saveris 2-H2

The WiFi data logger is ideal for monitoring temperature and relative humidity in rooms. Measurement data is sent to the testo Cloud (online data storage) via wireless LAN and can be accessed and evaluated on all internet-enabled end devices. The testo Cloud Basic package can be accessed free of charge.Internal data memory up to 10000 measured values per channelLimit values adjustable via testo-CloudE-mail notification when limit values are exceededCurrent measured values can be read on the displayMicro USB interface1 connection for external temperature and humidity probesAn external temperature and humidity probe is required to operate the testo Saveris 2-H2. Please order separately.Scope of supply: WiFi Temperature-humidity logger, testo-Cloud access (basic functionality), micro USB cable, wall bracket, batteries, calibration protocolSensor type:NTCMeasuring cycle:15 min ... 24 hCommunication cycle:15 min ... 24 hMemory:10000 measured values per channelDimensions:95 x 75 x 30.5 mmWeight:240 gPower supply:4 x AA AlMn Mignon batteriesIP code:IP54

From €310.00*

Temperature/Humidity data logger EBI 20-TH1-Set

Applications:Reliable temperature and temperature/humidity recordingTransportStorage monitoringRefrigeration areas and coldroomsFeatures:Excellent price/performance ratioVisual AlarmMax./min. values on displayStores 40000 readings, can be read off at any timeReplaceable batteryMeasuring mode: immediate loop measurement, measurement from starting point, start immediately until memory full, start/stop measuring, start when button pressedScope of supply: Temperature/Humidity logger, evaluation software, interface

From €144.90*

Temperature-humidity data logger Traceable®

Data logger with integrated sensors for monitoring temperature and relative humidity. The data logger can be connected to a Bluetooth®-enabled mobile device via the Bluetooth® interface. With the TraceableGO™ app (free of charge) or the TraceableLIVE™ cloud service (chargeable, registration required), measured values can be exported as a PDF, sent by e-mail, and stored on a mobile end device.Large LCD displayDisplay changes between temperature and humidity every 5 secondsSwitchable °C / °FLimit values and logging interval adjustable via TraceableGO™ or TraceableLIVE™ appStorage of up to 90 different alarm messagesNIST-traceable certificate includedScope of supply: Temperature-humidity data logger, batteries, NIST-traceable calibration certificateTemperature range:-20 ... 70 °CAccuracy:±0.4 °C (-10 ... 70 °C), ±0.5 °C remaining rangeResolution:0.1 °CHumidity range:0 ... 95 % RHAccuracy:±3 % RH (5 ... 75 % RH), ±5 % RH remaining rangeResolution:0.1 % RHLogging interval:1 min ... 12 hMemory:65536 measured valuesPower supply:2 x AAA

From €84.80*

Temperature and humidity logger LOG210 TC

Data logger with motion sensor, integrated USB interface for automatic PDF output and wall mount. For measurement and recording of temperature and humidity and 2 connections for external type K thermocouples.Freely adjustable recording interval from 10 seconds to 24 hoursMin- and Max-values can be reset in the displayTime marking function ("Time Marker") during data recordingWith movement sensor for shock recordingMemory for approx. 60000 measurementsAutomatic output as PDF file, device can also be used without softwareNo driver installation neededStatus and alarm LEDs, with buzzerDisplay can be switched offBattery life > 4 years at > 15 min measuring interval (free of charge)USB interface for data transferSoftware available for download on the manufacturer's websiteTemperature and humidity sensors are available separately.Scope of supply: Data logger, 2 thermocouples type K (1 m length), wall mount, battery, USB cover, screws and dowelsSpecificationsTemperature range internal: Temperature accuracy internal:-40 ... 70 °C ±0.5 °C (0 ... 60 °C), otherwise ±1 °CTemperature range external: Temperature accuracy external:-150 ... 1370 °C ±0.5 °C or 0.5 % (the greater value applies)Temperature resolution:0,1 °CHumidity range: Humidity accuracy:0 ... 100 % r.H. ±3 % r.H. (40 ... 60 % r.H.), ±3,5 % r.H., (20 ... 40 and 60 ... 80 % r.H.), otherwise ±5 % r.H.Humidity resolution:0.1 % r.H.Housing:ABSDimensions (W x D x H):42 x 20 x 91.5 mmWeight:70 gPower supply:1/2 AA 3.6 V

From €103.00*

Temperature, humidity, pressure and CO2 logger LOG220E

Data logger for temperature, humidity and pressure recording with an external connection for a CO2 sensor or humidity, pressure and temperature sensor.Freely adjustable recording interval from 10 seconds to 24 hoursMin- and Max-values can be reset in the displayTime marking function ("Time Marker") during data recordingWith movement sensor for shock recordingMemory for approx. 60000 measurementsAutomatic output as PDF file, device can also be used without softwareNo driver installation neededStatus and alarm LEDs, with buzzerDisplay can be switched offBattery life > 4 years at > 15 min measuring intervalUSB interface for data transferSoftware available for download on the manufacturer's website (free of charge)Temperature, pressure humidity and CO2 sensors are available separately.Scope of supply: Data logger, wall mount, battery, USB cover, screws and dowelsSpecificationsTemperature range internal: Temperature accuracy internal:-40 ... 70 °C ±0.5 °C (0 ... 60 °C), otherwise ±1 °CTemperature range external: Temperature accuracy external:-200 ... 850 °C ±0.2 °C or 0.3 % (the greater value applies)Temperature resolution:0.1 °CHumidity range: Humidity accuracy:0 ... 100 % r.H. ±3% r.H. (40 ... 60 % r.H.), ±3,5 % r.H. (20 ... 40 % and 60 ... 80 % r.H.), otherwise ±5 % r.H.Humidity resolution:0,1 %Pressure range: Pressure accuracy:300 ... 1100 hPa ±1 hPa (900 ... 1100 hPa), otherwise 0.5 % of end valuePressure resolution:0.1 hPaHousing:ABSDimensions (W x D x H):42 x 20 x 91.5 mmWeight:70 gPower supply:1/2 AA 3,6 V

From €133.00*

Mini temperature/pressure data logger EBI 11-TP210

The temperature/pressure data logger is specifically designed to measure temperature and pressure inside a bottle for pasteurization control.Space-saving stainless steel housingWireless measurementM5 threadTemperature-compensated pressure measurement over the complete measuring rangePT1000 temperature probe and piezoresistive pressure sensorMemory for up to 2 x 7500 measured valuesFactory calibration certificate: 0 °C, 60 °C, and 134 °C / 100 mbar, 3100 mbar, and 6000 mbar at 25 °C, 3100 mbar at 134 °CScope of supply: Temperature/pressure data logger

From €1,641.00*

Online humidity data logger testo 160 TH

Online data logger for automated temperature and humidity monitoring with an integrated temperature and humidity sensor. Measurement values are recorded and sent directly to the testo Saveris Cloud via an existing WLAN connection. In the cloud, data loggers can be configured, limit value alarms can be set and measurement data can be viewed and analysed. Thanks to the option of connecting to the testo Smart App, all measurement values can also be called up at any time and from anywhere using an internet-enabled smartphone, tablet or PC.Data transmission via WLANAutomatic measurement value documentation in testo Saveris CloudAlerting if limit values are exceeded via email, SMS or push notification (testo Smart App)Visual inspection on site thanks to large displayMemory for 32000 measured valuesTo operate the online data logger in the testo Saveris Cloud, a valid licence (subject to a charge) must be booked (Data Monitoring Licence).Scope of supply: Online humidity data logger, wall bracket, USB interface cable, 4 x AAA batteries, 2 x QR code sticker, test protocol

From €279.00*
